PVTsim Nova is a versatile PVT simulation program developed by Calsep for reservoir engineers, flow assurance specialists, PVT lab engineers, and process engineers. PVTsim Nova is an upgrade of the PVT simulation package: PVTsim.

PVTsim Nova is used by leading oil-producing and operating companies throughout the world.

Based on extensive data material collected over a period of more than 30 years, PVTsim Nova carries the information from experimental PVT studies into simulation software in a consistent manner and without losing valuable information on the way.

PVTsim Nova allows reservoir engineers, flow assurance specialists, and process engineers to combine reliable fluid characterization procedures with robust and efficient regression algorithms to match fluid properties and experimental data. The fluid parameters may be exported to produce high-quality input data for reservoir, pipeline, and process simulators.

PVTsim Nova is petroleum phase behavior at the tip of your fingers.

List of Updates from PVTsim Nova 5.0 to PVTsim Nova 6.0

FLUID DATA
• AUTO IMPORT OF PVT DATA FROM EXCEL SHEET
o Automated import of PVT reports in Calsep Excel format. A PVTsim installation comes with sample Calsep Excel PVT reports.
• PVT DATA IN PRODML XML FORMAT
o Automated import of fluid compositions and PVT data in PRODML XML version 2.1 format. o Import of multiple PRODML XML files in one operation. • ASPHALTENE AND WAX DATA o New dedicated tab on Fluid View for Asphaltene and Wax data.

FLUID MANAGEMENT
• FLUID EXPLORER
o Enhanced sorting features.
• IMPORT EXTERNAL EOS MODELS
o EoS models in the following formats can be imported: Eclipse Comp, PVTi, tNavigator Comp, Comptrack, CHC, Prosper EoS, GEM, and Winprop.

FLUID HANDLING
• USER CONTROLLED OBM CLEANING
o New OBM cleaning option that allows the user to define the contaminated carbon number range. The impact on simulated properties of the cleaned fluid is displayed.

PVT SIMULATION & REGRESSION
• DRY GAS CME (pVTZ)
o CME data can be entered and regressed to for a gas with no saturation point at the experimental temperature.
• AUTO EOS
o The requirement of at least two classical PVT experiments no longer exists if importance is assigned to the estimated mixture critical point.
• COMMON EOS w/ PLUS REGRESSION
o Bug corrected, which in rare cases resulted in a too-low molecular weight of the heaviest pseudo-component.

• MMP
o Tie-line plots added.
• CHARACTERIZED REGRESSION
o Option to prevent negative kids.
• TWO ALMOST IDENTICAL PRESSURE STAGES
o Two differential liberation pressure stages very close to each other no longer give an error.

RESERVOIR
• COMPOSITION ESTIMATION MODULE
o New module that uses the theory of chemical reaction equilibria to estimate how the composition of a reservoir fluid varies with temperature and pressure.
• COMPOSITIONAL GRADING
o Depth gradient option extended to possibly account for the increased compositional grading caused by viscosity effects (SPE 205887-MS).
• FAST SLIM TUBE
o Changed from a molar-based approach to a volumetric approach.

FLOW ASSURANCE
• ASPHALTENE SCREENING TOOL
o Outputs report that compiles De Boer plots, SARA-based methods, and EoS simulations for evaluating the risk of asphaltene problems.
• ASPHALTENE PHASE ENVELOPE
o Allowed for gas condensate fluids.
• SARA DATA
o Can be stored in a fluid database.
• WAX DATA
o PVTsim Nova database extended to hold wax appearance point, amount of wax in STO, and amount of wax precipitation with decreasing temperature (Wax Precipitation Curve – WPC).
• WAX TUNING
o Wax tuning options extended to also cover data for wax precipitation with decreasing temperature (WPC).
• HYDRATE PT CURVE
o The Hydrate PT curve option has been updated to handle a sudden shift in hydrate temperature from the dew to the bubble point side for a narrow boiling mixture.
• EMULSION VISCOSITIES
o Correction of oil-in-water viscosity, which was previously too low.
• WAX VISCOSITY CALCULATIONS
o Bug corrected to ensure that plots are always displayed correctly.

FLASH & PROCESS
• GAS QUALITY
o New option for calculating the NGL yield and gross heating value using either the GPA or the ISO standard.
• MULTI FLASH WITH SOLIDS
o New PT multi-flash option that handles pure inorganic and aqueous solid phases (e.g. CO2 and ice).
• T-BETA AND P-BETA FLASH OPTIONS
o Enhanced robustness of T-beta and P-beta flash options for mixtures with aqueous components.

• PT AQUEOUS FLASH
o The Aqueous phase properties can be calculated using the Water Package and the PC-SAFT as an alternative to the selected EoS.
• 3-PHASE SEPARATOR
o Logic changes to have water follow the oil until the last separation stage.
• OPEN STRUCTURE FLASH
o Updated to always output component fugacities for all phases.
• COPY PVT DATA
o Input checks have been relaxed for the option to copy PVT data between fluids.

MODELS & MODEL PARAMETERS
• MERCURY
o Hg properties and binary interaction parameters optimized to match experimental data.
• GERG-2008
o Enabled in PT-aqueous flash, PT multi-phase flash, 3-phase separator in Unit Operation menu, phase envelope with water, phase mapping, critical point, and in Saphir, Prosper, and MBAL interfaces.
• THERMAL CONDUCTIVITY OF THE AQUEOUS PHASE
o Hydrate inhibitors are taken into account when calculating the thermal conductivity of an aqueous phase.
o ASPHALTENE PARAMETERS
o Cubic EoS asphaltene parameters updated (SPE 203491-MS)
• BINARY INTERACTION PARAMETERS FOR GLYCOLS – C7+
o Updated kits for pairs of glycol (MEG, DEG, or TEG) and C7+.
• HELIUM
o Ideal gas Cp coefficients for He has been corrected.
• CARBON MONOXIDE
o CO added to the pure component database.

INTERFACES
• NEW INTERFACE MODULES
o OLGA batch option.
o Intersect Compositional.
o Turbulent Flux virtual meters.
o Open Porous Media (OPM) reservoir simulator.
• ECLIPSE BLACK OIL
o Refined monotonicity check.
• ECLIPSE COMP
o Extended with the option to account for the increased compositional grading caused by viscosity effects.
• GEM
o Updated to support T-dependent volume shift parameters.
• HYSYS
o C6 now appears as pseudo and et-benzene as e-Benzene in the Hysys interface file.
• IMEX
o Corrected to ensure that undersaturated Bg-values and gas viscosities deviate from saturated values.
• INTERSECT BLACK OIL

o Unit specification added to interface file
• INTERSECT COMP
o Extended with the option to account for the increased compositional grading caused by viscosity effects.
• NEXUS COMP
o Extended with the option to account for the increased compositional grading caused by viscosity effects.
• OLGA
o Artificial gas-phase enthalpies are forced to increase with increasing temperature.
o Bug corrected that might cause slightly inaccurate gas enthalpies for CO2-rich reservoir fluids.
• PIPESIM
o Incorrect values of H, S, and Cp at standard conditions corrected.
• PROSPER EOS
o Updated to support Prosper EoS version 16 in addition to version 7.
• navigator COMP
o Extended with the option to account for the increased compositional grading caused by viscosity effects.

OTHER
• LICENSE CHECK
o FLEXlm license check upgraded to version 11.17.
• HIGH-RESOLUTION MONITORS
o Some menus updated for a better user experience on high-resolution monitors.
• Z-FACTOR VERIFICATION REPORT
o Updated to also cover GERG-2008.
