Antenna Magus Pro 2022.1 v12.1.0 Win64

Antenna Magus is one of the best and most powerful software available for antenna design calculations. To design and build an antenna, we need to have high knowledge in the field of wave propagation, principles of microwave amplification and design of microwave amplifiers, and principles of impedance matching, which Antenna Magus software does in the best possible way. In this software, the user can easily select the required antenna from the antennas in the software database, which numbers more than 200, and after configuring its specifications according to their needs, the data is one of the soft Send microwave circuit design and simulation software such as CTS or AWR or FIKO for simulation and analysis.

From the 2020 version, this software, along with the CST STUDIO SUITE suite, has become the property of Dassault Systèmes.

Features and characteristics of Antenna Magus Professional software:

– Magus Explore Antenna:

Find your desired model in the software database and open it. Search among models can be done based on various parameters such as antenna type, antenna manufacturer, and. In the Explore section for all models, useful information such as model description, standard references used to design the model, and a brief explanation of how to use the model are listed.

– Antenna Magus Design:

The design environment of Antenna Magus software is completely regular and user-friendly and is completely similar to other commercial software in the field of antenna design. In this environment, the user can design the required antenna based on various parameters such as operating frequency, gain, input impedance, and. In the design process, the antenna and its parameters are checked by the software in terms of design rules, and if the values ​​entered by the user or other design parameters do not comply with the software rules, the relevant error is displayed to the user.

– Antenna Magus Estimate Performance:

In this section, the user can use a 3D electromagnetic simulator to simulate the designed antenna and view graphs such as frequency response, antenna impedance in terms of input frequency and برای for the designed antenna, and design errors and defects. Fix.

– Magus Antenna Export:

Antenna Magus software currently supports three software: FEKO, CST MICROWAVE STUDIO, and AWR Design Environment. In this software, the user can use the antenna model along with other parts of his circuit such as amplifiers, converters, and mixers to simulate all system components.
